Quality Assurance

3D Laser Scanning Confocal Microscope

TAIYO'S GOAL OF QUALITY? IT'S 100% QUALITY ASSURANCE OF PRODUCTS WITH HIGH RELIABILITY AND ENVIRONMENT FRIENDLY PERFORMANCE FOR ALL USERS.

With progress of the time, plating treatment is required to provide excellent adhesion property and solderability for high density circuitry pattern and high reliablity mounting. Namely the role of plating has transited from rust-preventive and decorative plating to high function and high reliability plating.TAIYO gives 100% quality assurance to all users by its chemical treatment engineering know-how which is accumulated throughout many years and company wide quality control system.


Heat cycle testing machine

  • Heat cycle testing machine

  • Scanning Electron Microscope

  • Ion Milling System

  • Total Organic Carbon Analyzer（TOC）
List of analyzers and testers
Use Analyzer and tester name
Observation and analysis of exterior appearance and surface Scanning electron microscopy energy dispersive X-ray analyzer, surface roughness tester, surface profiler, simple AOI machine, 3D vision measuring instrument, 2D vision measuring instrument, hole position accuracy measurement machine, 3D digital fine scope, interferometer, white-light interference microscope, digital microscope, Laser microscope, Ion Milling System
Character analysis Fluorescent X-ray film thickness meter, Eddy Current Thickness Meter, Magnetic Induction Thickness Meter, microhardness tester, Rockwell hardness tester, cohesive strength tester, multi solderability tester, reflow simulator, auto wire bonder, manual wire bonder, wire pull tester, ball shear tester, abrasion tester, eraser abrasion tester, temperature & humidity chamber, thermal shock chamber, salt spray tester, CAS tester, thermal conductivity tester, reflectance tester, surface tension balance, face contact angle meter
Inorganic analysis Ion chromatography, atomic absorption flame emission spectrophotometer, sequential plasma spectrometer, potentiometric automatic titrator, Rayny EDX
Organic analysis Gas chromatography, UV-VIS recording spectrophotometer, cyclic voltammetry stripping, high performance liquid chromatography, Total Organic Carbon Analyser
Other Other Liquid particle counter, air particle counter, vacuum gauge
